Teison DC Vision 60-240kW Ad Charger

$76,293.00 USD

Sale Sold out

Shipping calculated at checkout.

Power Output 60KW 90KW 120KW 150KW 160KW 180KW 200KW 240KW

features

• Solid design control box — Meets NEMA Type 4 & IP30 standard by lab test
• LCD color screen — Real-time status view and easy user interaction
• Breathing indicator light — Shows real-time charging status
• Control button — Adjust max output current & set scheduled charging time
• Water protection gasket — Resists 3-minute direct high-pressure water spray
• TPU cable — 14.76ft, excellent durability, cold resistant to -22°F
• ETL certified — Compliant with North American safety standards

Technical Specifications

Voltage: 240V/208V
Max Output Current: 40A (SS-PC1-100) / 32A (SS-HAY-100-32A)
Max Power: 8kW / 7kW
Frequency: 50/60Hz
Temperature Range: -22°F to 122°F
Humidity: 5–95%, no condensation
Connector: Type 1 (J1772)
Cable Length: 14.76ft (4.5m)
Altitude: ≤2000m (6,562ft)
Cooling: Natural
Safety Standards: ETL, UL2594, CSA C22.2
Scheduling: App / Timer control
Connectivity: Wi-Fi / Bluetooth
Warranty: 2 years

Packing Details

60 kW: supplier-listed packing weight 240 kg (529.1 lb); packed dimensions 1110 × 815 × 1880 mm.

90 kW: supplier-listed packing weight 360 kg (793.7 lb); packed dimensions 1150 × 950 × 2120 mm.

120 kW: supplier-listed packing weight 400 kg (881.8 lb); packed dimensions 1150 × 950 × 2120 mm.

150 kW: supplier-listed packing weight 400 kg (881.8 lb); packed dimensions 1150 × 950 × 2120 mm.

180 kW: supplier-listed packing weight 400 kg (881.8 lb); packed dimensions 1150 × 950 × 2120 mm.

240 kW: supplier-listed packing weight 440 kg (970.0 lb); packed dimensions 1150 × 950 × 2120 mm.

Figures correspond to standard floor-standing chargers; packaging for the 43-inch advertising-screen configuration is not separately confirmed. 160 kW and 200 kW figures not supplied.

Supplier did not separately specify whether weight is gross packed weight or the number of packages/crates; confirm before freight booking.

View full details

Teison DC Vision 60-240kW Ad Charger is a Teison 60–240 kw dc vision with advertising display intended for EV charging applications.

Key features

Manufacturer Teison EV charging equipment
Configuration-specific power and connector options
Technical requirements and accessories should be confirmed before ordering

Technical overview

Teison lists 60/90/120/150/160/180/200/240 kW configurations; 150–1000 V DC output; two charging outputs; 10.1-inch touchscreen plus 43-inch advertising display on current manufacturer family page; OCPP 1.6J / 2.0.1; IP55 enclosure. Display size requires confirmation for any variant quoted with 55-inch screen.

Confirm electrical compatibility, connector selection, installation requirements, availability and lead time before ordering.
