Sun Pumps SDS-Q-130 Solar Submersible Pump 1.4 – 4.0 GPM
Product Details
Sun Pumps SDS-Q-130 Solar Submersible Pump are highly efficient, low voltage, DC powered, diaphragm type positive displacement pumps designed specifically for water delivery in remote locations. Pumps operate on 12 to 30 volts of DC current that may be supplied from a variety of independent power sources including solar panels or batteries. Power requirements can be as little as 20 watts. Constructed of 316 and 304 stainless steel or all 316 stainless steel, these pumps are the highest quality submersible pumps in their class on the market.
Sun Pumps SDS-Q-130 series pumps can be installed below the water level in a pond, river or cistern, or installed by hand into a ground water well. They can be used to fill an open tank or in a pressurized water delivery system.
Simplicity is the key feature of the SDS series pumps. They are easy to install, require very little maintenance and are repairable.
Sun Pumps SDS series pumps are designed for use in stand alone water delivery systems. They are pollution-free, corrosion-free and self-lubricating. It is the ideal way to provide water for remote homes, campsites, livestock, small farms or for many other needs beyond the commercial power grid.
Specifications
- Depth Range: 80 feet (24 meters)
- Flow Range: 1.4 – 4.0 GPM (5.3 – 15 LPM)
- Max Load Current: 4.1 Amps
- Max Load Power: 123 Watts
- Discharge Size: 3/4″ NPT
- Minimum Well Diameter: 5″ (125mm)
- DC Voltage Range: 30-Dec
