ECO-WORTHY 5000W Solar Off-Grid Inverter Charger

Engineered for off-grid homes, cabins, RVs, and backup power, this all-in-one unit combines a 48V battery input, 120V AC split-phase output, and a built-in MPPT solar charger for seamless solar integration. It delivers a pure sine wave suitable for sensitive electronics and high-demand loads, with a 10,000W peak rating for surge needs.

Key capabilities

• Output: 120VAC split-phase, pure sine wave; Rated power 5000W, Peak power 10,000W
• Efficiency: >95%
• Inputs and charging: 48V battery input; AC input 110/120VAC; 50/60Hz auto-detect; MPPT solar charger up to 5000W, 500V open-circuit
• Solar charging: Max PV current 80A; MPPT range 120–450VDC; Max PV VOC 500V; Battery voltage range 40–60VDC
• Start and chemistry: Minimum start voltage 44V; supports lead-acid & lithium batteries
• Safety: Overload/short-circuit protection via circuit breaker; AC reverse protection; Bypass overload 40A
• Protection: Overcharge protection (alarm + auto stop); PV short-circuit protection (blown fuse)
• Smart features: Power Saving Mode activates when load ≤25W

Installation and maintenance

Designed for off-grid solar systems, hybrid installations, and emergency backups. Connect to a 48V battery bank and a PV array up to 5000W, ensuring PV voltage does not exceed 500V and that the AC input is 110/120VAC with a 90–140VAC range. The unit includes a 63A bypass breaker for safe isolation. Periodic inspections of battery connections and PV wiring, plus ensuring proper ventilation and clean enclosures, help maintain reliable performance.

Use cases and value

Ideal for off-grid homes, remote cabins, and mobile installations where robust power, clean power quality, and dependable surge capability are critical. The integrated inverter, charger, and MPPT solar controller reduce hardware complexity while supporting both lead-acid and lithium chemistries.

Eco-Worthy 5000W Solar Off-Grid Inverter Charger – 48V DC to 120V AC Split-Phase | Pure Sine Wave | 10,000W Peak

Power your off-grid home, cabin, RV, or backup system with the 5000W Solar Off-Grid Inverter Charger, engineered for high efficiency, stable performance, and seamless solar integration. This advanced all-in-one unit delivers pure sine wave output, 48V battery support, and 120V AC split-phase power, making it ideal for household appliances, tools, and sensitive electronics.

With 10,000W peak power, intelligent auto-detect frequency (50/60Hz), and a highly efficient >95% inverter design, this system provides dependable power even during demanding loads. The built-in MPPT solar charger handles up to 5000W of PV input, 500V open-circuit voltage, and 80A solar charging, ensuring fast, optimized energy harvesting.

Perfect for off-grid solar systems, hybrid setups, and emergency backup power, this inverter charger integrates AC charging, solar charging, and inverter mode in one powerful, reliable solution.

⭐ Key Features

AC Input Mode

• Rated Voltage: 110/120VAC

• Input Range: 90–140VAC

• Frequency: 50/60Hz (auto-detect)

• Efficiency: >95%

• Max Bypass Overload Current: 40A

• Overload/Short Circuit Protection: Circuit breaker

• AC Reverse Protection: Yes

Inverter Mode

• Pure Sine Wave Output – Safe for sensitive electronics

• Rated Power: 5000W

• Peak Power: 10,000W

• Output Voltage: 120VAC split-phase

• Rated Battery Input: 48V

• Minimum Start Voltage: 44V

• Power Saving Mode: Activates when load ≤ 25W

• Bypass Breaker: 63A

AC Charging Mode

• Compatible Batteries: Lead acid & Lithium

• Max Charge Current: 60A

• Charge Voltage Range: 40–60VDC

• Overcharge Protection: Alarm + automatic stop

PV (Solar) Charging Mode

• Max PV Input Power: 5000W

• Adjustable Solar Charge Current: 0–80A

• Max PV Open Circuit Voltage: 500VDC

• MPPT Operating Range: 120–450VDC

• Battery Voltage Range: 40–60VDC

• Charging Short Circuit Protection: Blown fuse

This 5000W off-grid inverter charger is the ideal solution for solar power systems, off-grid homes, remote cabins, battery backup setups, and hybrid installations requiring high power, high efficiency, and dependable pure sine wave output.
