BRAVO 50 DC | 50 Amp DC-DC Solar Charge Controller with MPPT

BRAVO 50 DC | 50 Amp DC-DC Solar Charge Controller with MPPT

$199.99 USD
$249.99 USD $199.99 USD
Sale Sold out
Shipping calculated at checkout.

features

• Solid design control box — Meets NEMA Type 4 & IP30 standard by lab test
• LCD color screen — Real-time status view and easy user interaction
• Breathing indicator light — Shows real-time charging status
• Control button — Adjust max output current & set scheduled charging time
• Water protection gasket — Resists 3-minute direct high-pressure water spray
• TPU cable — 14.76ft, excellent durability, cold resistant to -22°F
• ETL certified — Compliant with North American safety standards

Technical Specifications

Voltage: 240V/208V
Max Output Current: 40A (SS-PC1-100) / 32A (SS-HAY-100-32A)
Max Power: 8kW / 7kW
Frequency: 50/60Hz
Temperature Range: -22°F to 122°F
Humidity: 5–95%, no condensation
Connector: Type 1 (J1772)
Cable Length: 14.76ft (4.5m)
Altitude: ≤2000m (6,562ft)
Cooling: Natural
Safety Standards: ETL, UL2594, CSA C22.2
Scheduling: App / Timer control
Connectivity: Wi-Fi / Bluetooth
Warranty: 2 years

Packing Details

View full details

Equipment Type and Primary Applications: BRAVO 50 DC DC-DC Solar Charge Controller

The BRAVO 50 DC combines a 50A DC-DC charger with MPPT solar charging for mobile off-grid power systems. It charges 12V batteries from solar panels, a vehicle alternator, or both sources simultaneously or independently.

Performance Specifications

  • Rated charging current: 50A; 12V battery system with 9–16V operating range.
  • Maximum solar input: 55V DC, 50A, and 800W recommended PV capacity.
  • MPPT voltage range: 17–36V DC.
  • Alternator input: compatible with 12V or 24V systems; 65A maximum.
  • Efficiency: over 99% MPPT tracking; up to 96% power conversion.
  • Operating temperature: -35°C to +65°C (-31°F to +149°F).
  • Ingress rating: IP32. Dimensions: 8.70 × 6.92 × 3.64 in; weight: 5.16 lb.

Safety Features and Certifications

  • Electronic protection against overcharge, overcurrent, over-temperature, reverse polarity, and short circuit.
  • Certification marks and standards are not specified in the supplied product details.

Installation and Maintenance Requirements

  • Connect to compatible solar panels, a 12V/24V alternator, and a 12V battery system.
  • Allow installation space for the 8.70 × 6.92 × 3.64 in controller enclosure.
  • Use the built-in Bluetooth connection and RICH SOLAR App for monitoring and configuration.

Warranty and Service Information

Branding/References

  • Product: BRAVO 50 DC.
  • Communication references: Bluetooth, TTL, RS485, and CAN using the RV-C protocol.

Differentiators

PowerCatcher MPPT technology provides over 99% tracking efficiency, while buck MPPT and buck/boost charging support stable energy conversion from both solar arrays and vehicle alternators. Selectable solar or alternator charging priority adapts the controller to different mobile power requirements.
