BRAVO 50 | 50 Amp MPPT Solar Charge ControlleR

BRAVO 50 | 50 Amp MPPT Solar Charge ControlleR

$151.99 USD
$189.99 USD $151.99 USD
Sale Sold out
Shipping calculated at checkout.

features

• Solid design control box — Meets NEMA Type 4 & IP30 standard by lab test
• LCD color screen — Real-time status view and easy user interaction
• Breathing indicator light — Shows real-time charging status
• Control button — Adjust max output current & set scheduled charging time
• Water protection gasket — Resists 3-minute direct high-pressure water spray
• TPU cable — 14.76ft, excellent durability, cold resistant to -22°F
• ETL certified — Compliant with North American safety standards

Technical Specifications

Voltage: 240V/208V
Max Output Current: 40A (SS-PC1-100) / 32A (SS-HAY-100-32A)
Max Power: 8kW / 7kW
Frequency: 50/60Hz
Temperature Range: -22°F to 122°F
Humidity: 5–95%, no condensation
Connector: Type 1 (J1772)
Cable Length: 14.76ft (4.5m)
Altitude: ≤2000m (6,562ft)
Cooling: Natural
Safety Standards: ETL, UL2594, CSA C22.2
Scheduling: App / Timer control
Connectivity: Wi-Fi / Bluetooth
Warranty: 2 years

Packing Details

View full details

BRAVO 50 50A MPPT Solar Charge Controller

Equipment Type: MPPT solar charge controller
Primary Applications: 12V and 24V solar battery-charging systems using Crystal, GEL, AGM, Flooded (WET), Calcium, LCO, LFP, or LTO batteries.

Performance Specifications

  • Maximum PV charging current: 50A.
  • Recommended PV input power: 700W at 12V or 1,400W at 24V.
  • Maximum PV open-circuit voltage: 100V DC.
  • System nominal voltage: 12/24V with automatic detection.
  • MPPT tracking efficiency: >99.5%.
  • Charge conversion efficiency: ≤98%.
  • Housing: black/grey; dimensions: 7.7 × 5.5 × 2.9 in; net weight: 3.09 lb.
  • Protection ratings: IP43 for the internal PCBA and IP22 for the connection area.

Safety Features and Certifications

  • Electronic protection against over-voltage, reverse discharge, and circuit faults.
  • Common negative ground design for system integration.
  • Conformal-coated circuit board for improved durability in demanding environments.

Installation and Maintenance Requirements

Install in a compatible 12V or 24V solar charging system within the 100V DC PV open-circuit limit and recommended PV power range. During commissioning, connect the system so the controller can automatically detect nominal voltage. Use the built-in LCD to review solar input, battery status, and charging information. Bluetooth monitoring is available through the RICH SOLAR App. An optional remote meter and battery temperature sensor are supported.

Warranty and Service Information

Branding/References

Product: BRAVO 50. Monitoring reference: RICH SOLAR App. The supplied specifications identify the controller by the BRAVO 50 model name.

Differentiators

Its combination of >99.5% MPPT tracking efficiency, support for up to 1,400W of PV input at 24V, automatic 12/24V detection, and broad battery-chemistry compatibility supports adaptable solar charging system design.
