BRAVO 30 | 30 Amp MPPT Solar Charge Controller

BRAVO 30 | 30 Amp MPPT Solar Charge Controller

$103.99 USD
$129.99 USD $103.99 USD
Sale Sold out
Shipping calculated at checkout.

features

• Solid design control box — Meets NEMA Type 4 & IP30 standard by lab test
• LCD color screen — Real-time status view and easy user interaction
• Breathing indicator light — Shows real-time charging status
• Control button — Adjust max output current & set scheduled charging time
• Water protection gasket — Resists 3-minute direct high-pressure water spray
• TPU cable — 14.76ft, excellent durability, cold resistant to -22°F
• ETL certified — Compliant with North American safety standards

Technical Specifications

Voltage: 240V/208V
Max Output Current: 40A (SS-PC1-100) / 32A (SS-HAY-100-32A)
Max Power: 8kW / 7kW
Frequency: 50/60Hz
Temperature Range: -22°F to 122°F
Humidity: 5–95%, no condensation
Connector: Type 1 (J1772)
Cable Length: 14.76ft (4.5m)
Altitude: ≤2000m (6,562ft)
Cooling: Natural
Safety Standards: ETL, UL2594, CSA C22.2
Scheduling: App / Timer control
Connectivity: Wi-Fi / Bluetooth
Warranty: 2 years

Packing Details

View full details

Equipment Type and Primary Applications

BRAVO 30 is a 30 amp MPPT solar charge controller for 12V and 24V battery systems, supporting solar arrays up to 500W at 12V or 1,000W at 24V. It is designed for off-grid solar charging applications using GEL, AGM, WET, Crystal, Calcium, LiFePO4, LTO, LCO, and custom battery profiles.

Performance Specifications

  • Maximum solar input current: 30A
  • Maximum charging current: 30A
  • Nominal system voltage: 12V/24V with automatic detection
  • Solar input voltage range: 8V–100V
  • MPPT operating voltage range: 15V–72V
  • Maximum MPPT tracking efficiency: 99.5%
  • Maximum charge conversion efficiency: 98%
  • Protection rating: IP43 PCBA; IP22 connection area
  • Net weight: 1.8 lb; dimensions: 7.0 × 5.5 × 2.9 in

Safety Features and Certifications

Electronic protection addresses over-voltage, reverse discharge, and circuit faults. The conformal-coated circuit board supports operation in demanding environments. Certifications and compliance include UL 1741, FCC, CE, and RoHS.

Installation and Maintenance Requirements

Connect to a compatible 12V or 24V battery system and solar array within the stated voltage and power limits. The controller automatically detects system voltage during installation. Built-in Bluetooth connects to the RICH SOLAR App for real-time monitoring; an LCD displays solar input, battery status, and charging information. Optional accessories include a remote meter and battery temperature sensor.

Warranty and Service Information

Branding/References

Model: BRAVO 30. Monitoring reference: RICH SOLAR App.

Differentiators

Its 99.5% MPPT tracking efficiency, 100V maximum PV open-circuit input, dual-voltage auto-detection, and built-in Bluetooth monitoring combine flexible array design with detailed charging visibility.
