Green Vista Living

BatteryEvo 48V RHINO 4

BatteryEvo 48V RHINO 4

Regular price $7,059.00 USD
Regular price $7,145.00 USD Sale price $7,059.00 USD
Sale Sold out
Shipping calculated at checkout.
Quantity

features

• Solid design control box — Meets NEMA Type 4 & IP30 standard by lab test
• LCD color screen — Real-time status view and easy user interaction
• Breathing indicator light — Shows real-time charging status
• Control button — Adjust max output current & set scheduled charging time
• Water protection gasket — Resists 3-minute direct high-pressure water spray
• TPU cable — 14.76ft, excellent durability, cold resistant to -22°F
• ETL certified — Compliant with North American safety standards

Technical Specifications

Voltage: 240V/208V
Max Output Current: 40A (SS-PC1-100) / 32A (SS-HAY-100-32A)
Max Power: 8kW / 7kW
Frequency: 50/60Hz
Temperature Range: -22°F to 122°F
Humidity: 5–95%, no condensation
Connector: Type 1 (J1772)
Cable Length: 14.76ft (4.5m)
Altitude: ≤2000m (6,562ft)
Cooling: Natural
Safety Standards: ETL, UL2594, CSA C22.2
Scheduling: App / Timer control
Connectivity: Wi-Fi / Bluetooth
Warranty: 2 years

Packing Details

Package contents: Teison Portable Pro charger, TPU cable, user manual
Package weight: Please confirm with Ampere Authority


View full details

BatteryEvo 48V RHINO 4 – 40 kWh Energy Storage System for Large Homes, Commercial Buildings, and Off-Grid Installations

The BatteryEvo 48V RHINO 4 is a high‑capacity energy storage system designed to deliver reliable power for large residences, commercial facilities, and off‑grid applications. It seamlessly interfaces with AC mains, solar arrays, wind turbines, and generators to enable true energy independence and critical-load resilience. With a compact 600 lb cabinet footprint, it fits utility rooms, mechanical spaces, or equipment yards in both retrofit and new installations.

Performance specifications

  • Nominal voltage: 48 V; energy capacity: 40 kWh
  • Weight: 600 lb (272.16 kg); footprint: 43.3 in W × 15 in D × 32.1 in H
  • Real‑time state-of-charge (SOC) and voltage display for monitoring
  • Included in the bundle: 1 × 48V RHINO 4‑S; 4 AWG 4 ft BE175 to ring-terminal cable

Safety features and certifications

  • Zero‑maintenance lithium iron phosphate (LFP) cells
  • Surge protection to shield sensitive devices during transients
  • System design emphasizes safe operation within standard electrical environments

Installation and maintenance

  • Installation should be performed by a licensed technician in accordance with applicable electrical codes
  • Ensure secure mounting of the 600 lb cabinet and proper clearance for servicing
  • Zero‑maintenance cells minimize routine upkeep; periodic diagnostics by authorized service providers are recommended

Warranty and service

The batteries carry a 10‑year warranty. Comprehensive technical support and service are available through BatteryEvo.

Download Spec Sheet

BatteryEvo 48V RHINO 4

The BatteryEVO 40kWh RHINO 4 delivers reliable power for large homes, commercial buildings, and off-grid setups. Compatible with AC, solar, wind, and generators, it ensures full energy independence. Built for high-demand use, it keeps critical systems running without interruption.

➤ Real-time SOC and voltage display
➤ Surge protection for sensitive devices
➤ Zero-maintenance LFP cells
➤ 10-year warranty batteries

Included in this bundle:

  • 1.48V RHINO 4-S (x1)
  • 2.4AWG 4FT BE175 to Ring Terminal Cable (x1)

BatteryEvo 48V RHINO 4 - Green Vista LivingBatteryEvo 48V RHINO 4 - Green Vista Living

Weight: 600lbs (272.16kg)
Depth: 15.0in (380.84mm)
Width: 43.3in (1099.8mm)
Height: 32.1in (816.12mm)
