Anker SOLIX F3800 Plus Portable Power Station + Extra Battery
Equipment Type: Expandable LiFePO4 portable power station. Primary Applications: Whole-home backup, remote jobsites, off-grid cabins, EV top-offs, and solar microgrids.
Performance Specifications
- Total Capacity: 7,680Wh (3,840Wh base + 3,840Wh expansion)
- AC Output: 6,000W continuous, 12,000W surge
- Voltage: 120V/240V split-phase, L14-30R at 25A
- Chemistry: LiFePO4 cell (51.2Vdc 75Ah, 3,000+ cycles to 80%)
- Inputs: 1,800W AC, 3,200W dual-solar (11-165V, 17A/MPPT), 6,000W generator
- UPS Transition: 20ms
- Temp Range: Discharge -4°F–104°F; Charge 32°F–104°F
Safety Features and Certifications
- Fume-free internal chemistry ensures safe indoor/outdoor deployment
- Thermal cutoffs and pass-through routing prevent component stress during simultaneous charge/discharge cycles
Installation and Maintenance Requirements
Plug-and-play field setup. Circuit-panel integration requires a licensed electrician. Preservation involves periodic load verification and climate-controlled storage away from moisture.
Warranty and Service Information
Submit original purchase records to Anker support for standard coverage activation and regional repair routing.
Branding/References
- Manufacturer: Anker
- Model: SOLIX F3800 Plus + BP3800 Modular Battery
- Docs: Packaged user manual
Differentiators
- Stackable BP3800 modules scale system storage to 53.8kWh without external controllers
- Native 240V split-phase delivery eliminates costly external inverters for high-draw appliances
- Parallel AC/solar charging pathways maximize daily energy recovery during grid failure windows
| Specifications | Details |
| Battery Type | LiFePO4 Cell |
| Cell Part Number | 32140FS-15000mAh |
| Charging Cycle | 3000+ (to 80%) |
| Cell Capacity | 51.2Vdc 75Ah/3840Wh |
| Specifications | Details |
| AC Input | 120V~ 15A Max (< 3hrs) / 12A Max (continuous), 60Hz, L+N+PE |
| AC Input Power (Charging) | 1800W Max |
| AC Input Power (Bypass Mode) | 1440W Max |
| Solar Panel Input 1 | 11-165V - 17A Max (1600W Max Each) |
| Solar Panel Input 2 | 11-165V - 17A Max (1600W Max Each) |
| DC Input Port | 60V Max, 120A Max |
| Specifications | Details |
| Car Charger Output | 12V - 10A |
| Home Panel Power Port | 6000W Max (AC Input), 6000W Max (AC Output), 120V/240V, L1+L2+N+PE |
| AC Output Power (Total) | 6000W Max |
| AC Output 1 | 120V~ 20A Max, 60Hz, 2400W Max |
| AC Output 2 | 120V~ 20A Max, 60Hz, 2400W Max |
| AC Output (NEMA L14-30R) | 120V/240V~ 25A Max, 60Hz, 6000W Max |
| USB-A Output | 5V - 2.4A (12W Max Per Port) |
| USB-C Output | 5V - 3A / 9V - 3A / 15V - 3A / 20V - 3A / 20V - 5A (100W Max Per Port) |
| Specifications | Details |
| UPS | 20ms |
| Specifications | Details |
| Discharging Temperature | -4°F-104°F / -20°C-40°C |
| Charging Temperature | 32°F-104°F / 0°C-40°C |
| Specifications | Details |
| Size | 27.6×15.3×15.6 in / 70.2×38.8×39.5 cm |
| Net Weight | 62kg / 136.7lb |
| Specification | Details |
| Capacity | 51.2Vdc 75Ah / 3840Wh |
| Expansion Battery Port Input | 75A Max |
| Expansion Battery Port Output | 170A Max |
| Discharging Temperature | -4°F - 104°F | -20°C - 40°C |
| Charging Temperature | 32°F - 104°F | 0°C - 40°C |
| Dimensions | 15.5 × 14.0 × 10.3 in | 39.3 × 35.5 × 26.2 cm |
| Net Weight | 33 kg | 72 lb |
