Rich Solar - All-in-One Energy Storage System

Rich Solar - All-in-One Energy Storage System

$6,899.00 USD
$10,999.99 USD $6,899.00 USD
Sale Sold out
Shipping calculated at checkout.

features

• Solid design control box — Meets NEMA Type 4 & IP30 standard by lab test
• LCD color screen — Real-time status view and easy user interaction
• Breathing indicator light — Shows real-time charging status
• Control button — Adjust max output current & set scheduled charging time
• Water protection gasket — Resists 3-minute direct high-pressure water spray
• TPU cable — 14.76ft, excellent durability, cold resistant to -22°F
• ETL certified — Compliant with North American safety standards

Technical Specifications

Voltage: 240V/208V
Max Output Current: 40A (SS-PC1-100) / 32A (SS-HAY-100-32A)
Max Power: 8kW / 7kW
Frequency: 50/60Hz
Temperature Range: -22°F to 122°F
Humidity: 5–95%, no condensation
Connector: Type 1 (J1772)
Cable Length: 14.76ft (4.5m)
Altitude: ≤2000m (6,562ft)
Cooling: Natural
Safety Standards: ETL, UL2594, CSA C22.2
Scheduling: App / Timer control
Connectivity: Wi-Fi / Bluetooth
Warranty: 2 years

Packing Details

Package contents: Teison Portable Pro charger, TPU cable, user manual
Package weight: Please confirm with Ampere Authority


View full details

Rich Solar All-in-One Energy Storage System

The Rich Solar All-in-One Energy Storage System is a compact, integrated solution that combines an inverter, batteries, and a charge controller into a single enclosure for clean, reliable electricity. Designed for off-grid and grid-tied applications, it delivers pure sine-wave power with programmable supply priority (PV, Battery, or Grid), user-adjustable charging, and a battery-independent architecture. The system supports scalable Li‑Ion expansion and includes multi‑interface communications, real-time monitoring via a mobile app, and compatibility with utilities and generators for flexible energy management in space-constrained environments.

SPECIFICATION

  • Model: RS-A10
  • Maximum PV Input Power: 8000 W
  • Rated Output Power: 6500 W
  • Maximum Charging Power: 6500 W
  • PV Input (DC): MPPT Range 90–230 VDC
  • Maximum PV Open Circuit Voltage: 250 VDC
  • Maximum Solar Charge Current: 120 A
  • Number of MPPT Trackers: 2
  • AC Input Voltage Range: 90–140 VAC (Computers); 80–140 VAC (Home)
  • Maximum AC Input Current: 60 A
  • Nominal Battery Voltage: 48 VDC
  • Battery Capacity: 5120 Wh; Typical Capacity 100 Ah
  • Nominal Output Voltage (Battery Mode): 120 VAC
  • Maximum Conversion Efficiency (DC/AC): 93%
  • Float Charge Voltage: 52.5 V
  • Charge Current (Standard): 20 A (0.2C)
  • Maximum Charge Current: 50 A (0.5C)
  • Standard Charge Method: CC 0.2C to FC, CV until current < 0.05C
  • Battery System Dimensions: 8.4" x 24.4" x 19.7"
  • ALL-IN-ONE System Dimensions (D x W x H): 19.7" x 26" x 49.2"
  • Net Weight (System): 287 lb
  • Safety Certifications: IEC 62619; EN 61000-6-3; EN 61000-6-1; UKCA; UN38.3; UL 1741; CSA C22.2 No.107.1-16; FCC Part 15B

INSTALLATION & MAINTENANCE

  • Professional installation is recommended to ensure proper integration with PV, utility, and generator sources and to meet local electrical codes.
  • Place in a well-ventilated, dry area with adequate clearance for service and cooling.
  • Consult the included USER MANUAL for wiring diagrams, commissioning steps, and maintenance guidelines.
  • Regularly inspect electrical connections and BMS status; verify protection devices are intact.

SAFETY & CERTIFICATIONS

  • Safety standards and compliance: IEC 62619; EN 61000-6-3; EN 61000-6-1; UKCA; UN38.3; UL 1741; CSA C22.2 No.107.1-16; FCC Part 15B.
  • Protection features include an integrated BMS and protective breakers to safeguard the battery and system.

COMMUNICATIONS & MONITORING

  • Multi‑interface connectivity: USB, RS232, SNMP, Modbus, GPRS, and Wi‑Fi for remote monitoring and control.
  • Real-time status display and parameter control via Monitoring APP (Android and iOS).
  • Programmable supply priority allows tailoring energy flow among PV, battery, and grid to suit specific applications.

Rich Solar - All-in-One Energy Storage System

The RICH SOLAR All-in-One Energy Storage System is a powerful and efficient solar energy system designed to provide clean and reliable electricity. This innovative system integrates all the components required for solar power generation into a single, compact unit, including an inverter, batteries, and a charge controller.


All in One Energy Storage System Features

🗹 Pure sine wave output

🗹 Off-Grid application

🗹 Programmable supply priority for PV, Battery, or Grid

🗹 User-adjustable battery charging current

🗹 Battery independent design

🗹 Multiple communication for USB, RS232, SNMP, Modbus, GPRS and Wi-Fi

🗹 Monitoring APP (Android and iOS) for real-time status display and parameter control

🗹 Built-in 2 MPPT trackers and AC/Solar charger up to 120A

🗹 Compatible with utility and generator

🗹 Scalable Li-Ion battery expansion

All in One Energy Storage System Features
The compact design of an All-in-One Energy Storage System makes it an attractive option for those with limited space, or for those who want a more discreet installation. It can also be easier to install and maintain compared to larger energy storage systems, which may require more extensive wiring and infrastructure.

Tech Specs

Specifications


BATTERY INFO

Model:

RS-A10

Maximum PV Input Power:

8000W

Rated Output Power:

6500W

Maximum Charging Power:

6500W

PV INPUT (DC)

MPPT Range @ Operating Voltage:

90 ~ 230 VDC

Maximum PV Array Open Circuit Voltage:

250 VDC/p>

Maximum Solar Charge Current:

120A

Number of MPP Trackers / Maximum Input Current:

2 / 2 x 18 A

AC INPUT

Acceptable Input Voltage Range:

90-140 VAC (For Computers)
80-140 VAC (For Home Appliances)

Maximum AC Input Current:

60A

BATTERY MODE OUTPUT

Nominal Output Voltage:

120 VAC

Maximum Conversion Efficiency (DC/AC):

93%

BATTERY

Nominal DC Voltage:

48 VDC

Maximum Charging Current:

120 A

Dimension:

(D x W x H): 8.4" x 24.4" x 19.7"

Net Weight:

99 lb

Capacity:

5120Wh

Nominal Voltage:

51.2VDC

Full Charge Voltage(FC):

56V

Full Discharge Voltage(FD):

42V

Typical Capacity:

100 Ah

Max Continuous Discharging Current:

120A

Max Discharging Current:

192A at 1 min

Protection:

BMS, Breaker

Float Charge Voltage:

52.5V

Charge Current:

20A (0.2C)

Maximum Charge current:

50A (0.5C)

Standard Charge method:

0.2C CC (Constant current) charge to FC, CV (Constant voltage FC) charge till charge current declines to <0.05C

Inner Resistance:

=20m ohm

ALL IN ONE SYSTEM PHYSICAL

System Dimension (D X W X H):

19.7" x 26" x 49.2"

Net Weight:

287 lb

STANDARD

Compliance Safety:

IEC 62619, EN 61000-6-3, EN 61000-6-1, UKCA, UN38.3, UL 1741, CSA C22.2 No.107.1-16, FCC PART 15B

Specification & User Manual

All in One Energy Storage System

ALL IN ONE ENERGY STORAGE SYSTEM
