Rich Solar - 1200 Watt Solar Kit
The Rich Solar 1200W Kit delivers a robust 24V off-grid solar solution for RVs, boats, trailers, and other mobile applications. Comprising six 200W monocrystalline panels and a 60A MPPT charge controller, it provides quiet, reliable power with easy plug‑and‑play expansion to meet growing energy needs.
Key specifications
- Six 200W Monocrystalline panels (RS-M200) with 9 busbars
- Total system power: 1200W at 24V
- Panel electrical: Vmp 20.4V, Imp 9.80A; Voc 24.3V, Isc 10.2A
- Panel dimensions: 58.7 × 26.8 × 1.4 in; weight 26.5 lb each
- 60A MPPT Solar Charge Controller (RS-MPPT60) with real-time volts, amps, and amp-hours
- Pre-assembled wiring harness; no crimping tools required
- Included: 20 ft #10 solar cables (red/black), 10 ft #8 battery cables (red/black), inline fuse, mounting brackets, and Y-branch adapters
Safety, monitoring and durability
The MPPT controller provides real-time monitoring and overcharge protection, helping maximize efficiency and safeguard your system. The inline 30A fuse adds protective redundancy, while anti-reflective coating on the panels enhances light absorption for higher energy yield.
Installation and maintenance
Designed for straightforward RV, trailer, and van installations, the kit’s pre-wired harness enables quick setup and straightforward expansions with other Rich Solar components. Maintain performance by keeping connectors clean and free from corrosion and by regularly inspecting mounting hardware.
Warranty and service
25-year output warranty ensures long-term performance. The kit is designed to pair with a 24V battery bank (e.g., 300Ah) to power most RVs, boats, or trailers with confidence.
Rich Solar - 1200 Watt Solar Kit
This 24V 1200W kit contains 6 high-efficiency 200W Monocrystalline panels with 9 busbars and our 60A MPPT controller. This DIY RV solar kit can be paired with a 300AH 24V battery bank and can power most RVs. For a quieter, more peaceful outdoor experience, go solar now and start powering your RV, boat, or trailer!
Package Includes
🗹 6 x 200 Watt Monocrystalline Solar Panel(RS-M200)
🗹 1 x 60A MPPT Solar Charge Controller(RS-MPPT60)
🗹 1 x 20' #10 Gauge Solar Cable (Red), connects the solar panel to the controller(RS-20101)
🗹 1 x 20' #10 Gauge Solar Cable (Black), connects the solar panel to the controller(RS-20101)
🗹 1 x 10' #8 Gauge Battery Cable (Red), connects the controller to the battery (RS-810)
🗹 1 x 10' #8 Gauge Battery Cable (Black), connects the controller to the battery (RS-810)
🗹 6 x Mounting Z Brackets (one set of 4)(RS-ZB4C)
🗹 1 x 30A Inline Fuse Holder with Fuse (RS-SC30F)
🗹 1 x Y Branch Parallel Adapters(RS-T2)
High-Efficiency Solar Panel
With the highest-grade monocrystalline solar cells for optimal output, our 200 watt panel is treated with an anti-reflective coating to maximize light absorption.
Simple Installation
RV solar installation is a breeze with our pre-assembled wiring harness that doesn’t require crimping tools. Since all of our products are compatible with each other, making expansions, upgrades, or additions simple and easy… just plug in and go! Installing solar panels on RVs, trailers, and vans has never been easier.
Reliable and Convenient
The digital MPPT charge controller lets you gauge your power with a glance, providing real-time updates of volts, amps, and amp hours. provide peace of mind by protecting your system from overcharging.
25-Year Output Warranty
Buy with confidence knowing that your off-grid RV solar system investment will last for the long haul.
200 Watt Solar Panel Specifications
Maximum Power(Pmax): 200W
Maximum Power Voltage(Vmp): 20.4V
Maximum Power Current(Imp): 9.80A
Open Circuit Voltage(Voc): 24.3V
Short Circuit Current(ISC): 10.2A
Weight: 26.5 lbs
Dimensions: 58.7 x 26.8 x 1.4 in
Warranty: 25 years output warranty
