60A MPPT solar charge controller

60A MPPT solar charge controller

$239.99 USD
$299.99 USD $239.99 USD
Sale Sold out
Shipping calculated at checkout.

features

• Solid design control box — Meets NEMA Type 4 & IP30 standard by lab test
• LCD color screen — Real-time status view and easy user interaction
• Breathing indicator light — Shows real-time charging status
• Control button — Adjust max output current & set scheduled charging time
• Water protection gasket — Resists 3-minute direct high-pressure water spray
• TPU cable — 14.76ft, excellent durability, cold resistant to -22°F
• ETL certified — Compliant with North American safety standards

Technical Specifications

Voltage: 240V/208V
Max Output Current: 40A (SS-PC1-100) / 32A (SS-HAY-100-32A)
Max Power: 8kW / 7kW
Frequency: 50/60Hz
Temperature Range: -22°F to 122°F
Humidity: 5–95%, no condensation
Connector: Type 1 (J1772)
Cable Length: 14.76ft (4.5m)
Altitude: ≤2000m (6,562ft)
Cooling: Natural
Safety Standards: ETL, UL2594, CSA C22.2
Scheduling: App / Timer control
Connectivity: Wi-Fi / Bluetooth
Warranty: 2 years

Packing Details

View full details

60A MPPT Solar Charge Controller

Equipment Type and Primary Applications

60A MPPT solar charge controller for off-grid battery charging systems using 12V, 24V, 36V, or 48V battery banks. It is suitable for solar arrays up to 800W at 12V, 1,600W at 24V, 2,400W at 36V, or 3,200W at 48V, supporting sealed, gel, flooded, and lithium batteries.

Performance Specifications

  • Rated battery charging current: 60A; rated load current: 20A.
  • MPPT tracking efficiency: up to 99%; conversion efficiency: up to 98%.
  • Maximum solar input voltage: 150V at 77°F; 145V at -13°F.
  • Charge circuit voltage drop: ≤0.26V; discharge circuit voltage drop: ≤0.15V.
  • Operating temperature: -31°F to 113°F.
  • Die-cast aluminum housing supports heat dissipation. Overall dimensions: 11.2 x 8.1 x 3.7 inches; net weight: 7.94 lb.

Safety Features and Certifications

Electronic protection covers reverse polarity, overcharging, overload, and short circuit conditions. The controller also supports recovery charging for over-discharged lithium batteries. Certification marks and standards are not specified.

Installation and Maintenance Requirements

Install within a compatible 12V/24V/36V/48V system and connect solar, battery, and load wiring within the maximum terminal size of 11mm. The controller automatically detects system voltage during installation. LCD and LED indicators display charging status, battery information, operating parameters, and fault codes. The RS232 port supports the optional BT-1 Bluetooth module for wireless monitoring.

Warranty and Service Information

Branding/References

Product: 60A MPPT solar charge controller. Optional accessory reference: BT-1 Bluetooth module.

Differentiators

Automatic support for four nominal system voltages, 150V solar input capability, lithium battery recovery, and up to 99% MPPT tracking efficiency provide flexible control for changing off-grid system requirements.
